| Model | 1325 |
|---|---|
| X-Y Axis Working Area | 1300mm x 2500mm x 200mm |
| Spindle Power | 4.5kw Air cooling spindle |
| Inverter | 5.5Kw |
| Spindle Speed | 18000 to 24000 rpm/min |
| Table | T-slot aluminum 1.2mm |
| Guide Rail | Square guide rail 25mm |
| Gear Rack | 1.25mm |
| Gantry | 8mm thick bridge, cast steel support |
| Motor | Leadshine Hybrid servo Driver |
| Working Speed | 6000 to 24000 rpm |
| Working Voltage | 220v 1 ph 50hz, Single Phase |
| Running Circumstance Temperature | 0°C – 45°C |
| Controller | DSP Controller A11 |
| Dust Collector | Double Bag |
