Plywood wood leather acrylic paper glass Co2 laser cutting engraving machine is suitable to seal cutting, advertisement, art gift, garment, leather, toy, building upholster, computerized embroidery, packing and printing, paper product, garments sampling, large width tailoring, shoe making, furniture, industry, craftwork, nameplates decorations, woodcut and other industries.
| Specification | Details |
|---|---|
| Laser Tube | CO₂ Glass Tube |
| Laser Power | 80W |
| Cutting Speed | 0 – 36,000 mm/min |
| Engraving Speed | 0 – 30,000 mm/min |
| Resolution | ± 0.05mm / 1000 DPI |
| Minimum Letter Size | Character: 2×2mm, Letter: 1×1mm |
| Supported File Formats | BMP, HPGL, PLT, DST, AI |
| Port | USB 2.0 (Plug & Play) |
| Software | CorelDraw (Direct Output) |
| Motor | Stepper |
| Power Voltage | AC 110–220V ±10%, 50–60Hz |
| Working Environment | 0–45°C, 5–95% Humidity |
| Power Consumption | < 300W |
| Table Type | Aluminum |
| Z-Axis Movement | Automatic, 0–300mm Adjustable |
| Positioning System | Red Dot Pointer |
| Cooling Method | Water-Cooled System |
| Cutting Thickness | 0–20mm (varies by material and laser power) |
| Packing Size | 122 × 80 × 78 cm |
| Material | Engraving | Cutting |
|---|---|---|
| Acrylic | ✔ | ✔ |
| Wood | ✔ | ✔ |
| Bamboo | ✔ | ✔ |
| Glass | ✔ | ✘ |
| Leather | ✔ | ✔ |
| Paper | ✔ | ✔ |
| Rubber | ✔ | ✔ |
| Textile | ✔ | ✔ |
| Plastic | ✔ | ✔ |
| Metal | ✘ | ✘ |
| Stone | ✔ | ✘ |
| Ceramic | ✔ | ✘ |
