Model

GZM3204SG

Print Head

4 Starfire 1024(25pl) / 2 Starfire 1024(25pl)

Ink

C.M.Y.K Solvent / Eco-Solvent

Ink Supply System

Gntek Negative Pressure Recirculation System

Printing Width

Max. 3200mm

Media Type

Banner, Frontlit, Backlit, Vinyl, Film...

Feeding System

Automatic Media Feeding and Taking up System with Pneumatic Shaft

Drying System

Pre, Mid, Post and Extended Heater Plus Intelligent IR Drying System

Printing Speed

GZM3204SG

300x400dpi 229㎡/h

600x400dpi 177㎡/h

300x600dpi 164㎡/h

600x600dpi 125㎡/h

300x800dpi 128㎡/h

600x800dpi  97㎡/h

Data Interface

External: USB2.0; Internal: High-Speed SCSI

Working Environment

Temp. 23℃~29℃, Humidity: 50%~80%

Software

Onyx+GZ Control Console

Power

50Hz/AC, 220V±10% 13A(Printer)+18Ax2(IR Drying System)

Installed / Packed Size

LxWxH(mm)：4660x962x1250 / 4930x1150x1690

G.W. / N.W.

1345KGS / 1115KGS
