This is Fiber Laser Marking Machine suitable for a wide range of industries. Fiber Marking can be done on Ceramic, Plastics, Acrylic, Leather, PU, Stainless Steel, Carbon Steel, Aluminium, Wood, Paper, etc
| Parameter | Details |
|---|---|
| Model | Fiber Laser Marking Machine |
| Laser Source | 20W / 30W / 50W Max |
| Wavelength | 1064 nm |
| Working Area | 200 × 200 mm |
| Galvo Brand | Sino-Galvo |
| Mainboard | BJJCZ |
| Software | EZCAD |
| Marking Depth | < 0.8 mm |
| Working Speed | < 8000 mm/s |
| Minimum Symbol Size | 0.15 mm |
| Minimum Line Width | 0.01 mm |
| Repeat Accuracy | ±0.0025 mm |
| Voltage | AC 220V / 50Hz or 110V / 60Hz |
| Total Power Consumption | 0.5 kW – 0.8 kW |
| Cooling Method | Air Cooling |
| Red Light Positioning | Yes |
| Working Environment | Temperature: 5–40°C, Humidity: <80% |
| Machine Weight | 30 KG |
| Package Size | 920 × 770 × 1250 mm |
| Gross Weight | 50 KG |
| Package Volume | 0.89 CBM |
High-speed marking with precision galvanometer.
Lightweight and space-saving design.
Low power consumption (< 500W).
Fully air-cooled—no chiller required.
Reliable operation even in harsh environments and fluctuating temperatures.
Can operate on battery or car inverter if AC power is unavailable.
Long lifespan: 100,000 hours of fiber laser usage.
High electro-optic conversion efficiency (>28%).
Integrated circuits & semiconductors
Computer & electronic components
Aerospace and automotive parts
Jewelry and luxury goods
Tools, dies, bearings, wires
Food & medicine packaging
Watches, glassware, hardware
Gold & silver
Stainless steel
Aluminum
Glass
Stone
Leather
Plastics (ABS, PVC, etc.)
