Topjet-i KM 512i- 3204, 3208

1-Topjet-i-KM512i-3204-3208 copy
3-Topjet-i-KM512i-3204-3208
2-Topjet-i-KM512i-3204-3208
4-Topjet-i-KM512i-3204-3208

Specifications:

Equipment Model C4 E8 59
Control Bed BYHX
Carriage Motor Fuji 400W
Drag Chain Germany IHUS Drag Chain
Carriage Belt Germany JAGDFLAKE
Linear Guide Japan THK with mute the slider
Printer Frame High Quality & strong printer frame
Beam Aluminum beam/sheet metal(straightness 0.1mm,fatness 0.05mm)
Carriage Lift type carriage
Nozzle type KMS512i-30pl
Nozzle Height 1-10mm
Maximum printing width 3200mm
Apply the ink Solvent ink
Applied materials Light box doth/coiled material
Ignition frequency 20KHZ
Printing speed 2pass                    3pass                     6pass                 8pass
(4H)140m2/h          90m2/h             45m2/h              35m2/h
(8H)280m2/h          180m2/h             90m2/h            70m2/h
Print Accuracy 480*360dpi   480*540dpi   720*1080dpi   720*1440dpi
RIP Software Maintop/Photoprint/Ultraprint
Nozzle Moisturizing Industrial nozzle special device
Drying system Intelligent infrared heating & drying system
feed/collect system Auto feed/collect system
Environement conditions temperature:16-30C Relative humidity:40%-60%
Power supply ACC220/1500W(print) 3000W (Dry)
Product Size(mm) 5000*1200*1700mm
Product Weight 1100KG
6-Topjet-i-KM512i-3204-3208
5-Topjet-i-KM512i-3204-3208
7-Topjet-i-KM512i-3204-3208
8-Topjet-i-KM512i-3204-3207
